Dihai is a prominent manufacturer of high-end fully automatic electronic cigarette filling machines in China. Our comprehensive solutions cover all processes and systems, and our Vape cartridge filling machine has gained significant popularity in the United States. Key products include fully automatic small cigarette filling machines, semi-automatic small cigarette filling machines, fully automatic small cigarette capping machines, atomizer work testing machines, and disposable pen bubble testing machines.
ODM/OEM Services
We offer a wide range of ODM and OEM services tailored to electronic cigarette machinery.
Professional Team
Our team is characterized by a strong collaborative spirit and a commitment to exceeding customer expectations.
Quality Assurance
Each shipment is accompanied by a detailed quality inspection report, ensuring transparency and addressing any concerns regarding product quality.
Efficient Transportation
Through partnerships with professional sea freight, air freight, and logistics companies, we provide optimal transportation solutions to meet your needs.
|
Input voltage (V) |
Single-phase AC110~220VAC 50Hz |
|
Input power capacity (power) |
50W |
|
Measurement range of air pressure |
0~5kPa, precision: 2% |
|
Equipment dimension (mm) |
350x300x250 |
|
Equipment weight |
10kg |
|
Environmental conditions |
Temperature: 0~150℃ |
|
Vacuum pressure Kpa |
-50Kpa~0Kpa |
Types of Testing Machine
The testing machines produced by our company mainly include the following types:
Smoking Test Machine
Test the comprehensive performance of electronic cigarettes and determine whether the device is qualified. It is suitable for various electronic cigarette testing, and can be equipped with corresponding silicone molds according to different cigarette holders to achieve different electronic cigarette product testing.
Suction Resistance Temperature Testing Machine
The suction resistance and temperature measurement testing machine refers to an integrated suction resistance and temperature testing machine that can simultaneously inject oil into multiple electronic cigarettes quickly, conveniently, and accurately.
Advantages of Testing Machine
Improved Product Quality
By subjecting vape products to comprehensive and accurate testing, the automatic testing machine helps manufacturers identify and correct any potential issues before the products reach the market. This results in higher - quality products that are more reliable and provide a better vaping experience for consumers.
Regulatory Compliance
The vape industry is subject to various regulations regarding product safety and quality. The use of automatic testing machines enables manufacturers to ensure that their products meet these regulatory requirements. This reduces the risk of non - compliance fines and product recalls, protecting both the company's bottom line and the consumers.
Cost - Effective Production
Although the initial investment in an automatic testing machine may be significant, in the long run, it can lead to cost savings. By reducing the number of defective products that need to be reworked or scrapped, manufacturers can lower their production costs. Additionally, the high - speed testing capability of the machine allows for more efficient production lines, increasing overall productivity.
Applications of Testing Machine
It can be used to test various electronic cigarettes. It can be outfitted with corresponding silica gel molds based on different cigarette holders in order to test various electronic cigarette products.
1. Connect the power supply, switch on and off the power switch, and the power indicator light will be on;
2. Before starting the machine, adjust the test time and set the timer, as follows:
● Time relay setting method: As shown in the above figure, each function is displayed, with the left side being the disconnection time setting and the right side being the contact time setting; Adjust the time setting above and below the number (adjustment keys "+" and "-"), such as pressing the "-" button above the number to decrease the time; Press "+" below the number to add the time.
● The time unit modes include: "0.1S", "S", "0.1M", "M", "0.1H", and "H", as shown on the right side of the figure; You can switch time units by pressing the up and down (adjustment keys "+", "-");
● The cycle time setting of this device uses the right side (contact zone) function of the time relay, and the time is adjusted to 2S (this time can be appropriately adjusted based on the actual needs of the device). Set the function on the left (disconnection interval), and adjust all the numbers to "2S" (this time can be adjusted appropriately based on the actual needs of the device);
● Air pump pressure regulation: First, adjust the right function of the time relay to 2S, and the start indicator light remains on. Adjust the air pump A, rotate the pressure regulator A clockwise, and block the test hole A with your hand. Observe the pressure displayed on the pressure gauge A, and adjust the required pressure. The general pressure is 1-2kPa (this pressure can be adjusted appropriately based on the actual needs of the equipment). Similarly, adjust air pump B.
Packaging and Shipping
|
Packaging |
We use standard export plywood boxes for packaging, which are customized according to the size of the machine. |
|
Shipping |
Support variety methods of shipments, such as by DHL/Fedex/UPS, by air, by sea, by train door to door. |
Our Factory
Dihai, founded in 2008. The first world original manufacturer for filling and capping various type of vape cartridges, disposable pen pods cartridges glass syringes, capsules dihai rob focus on saving your time and labor forfilling and capping work since 2008 services for CBD marijuana industry! In order to expand overseas business, Dihai ROB has established sales offices in Shenzhen, Dongguan, and the United States.
